Lexus NX 2014–2017

1 generation (AZ10)

At a glance

Engine1986 cm3 Gasoline

Power238 hp

GearboxAutomatic

OriginN/A

Trim

200 CVT (150 hp)200 CVT AWD (150 hp)200t AT AWD (238 hp)2.0 AT AWD (238 PS)2.0 CVT (150 PS)2.0 CVT AWD (150 PS)2.5 CVT AWD (155 PS)300h CVT AWD (197 hp)

Specifications

Engine

Max power (kW)177 kW

Capacity1986 cm3

Engine power238 hp

Engine power241 PS

Maximum torque350 N*m

Number of cylinders4

Valves per cylinder4

Injection typedirect injection

Turnover of maximum torquefrom 1 650 to 4 000 RPM

Max power at RPMfrom 4 800 to 5 600 RPM

Engine typeGasoline

Cylinder layoutInline

Presence of intercoolerPresent

Boost typeTurbo

Bodywork

Max trunk capacity1546 l

Front track1580 mm

Rear track1580 mm

Height1645 mm

Curb weight1735 kg

Width1845 mm

Ground clearance190 mm

Wheelbase2660 mm

Length4630 mm

Number of seater5

Min trunk capacity500 l

Body typeCrossover

Gearbox and handling

Turning circle11.4 m

Number of gear6

Gearbox typeAutomatic

Drive wheelsFour wheel drive (4WD)

Operating characteristics

City driving fuel consumption per 100 km10.2 l

Max speed200 km/h

Fuel tank capacity60 l

Acceleration (0-100 km/h)7.2 s

Highway driving fuel consumption per 100 km8.4 l

Mixed driving fuel consumption per 100 km8.8 l

Fuel95

Emission standardsEURO V

Cruising rangefrom 590 to 710 km

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, McPherson Struts

Back suspensionMulti wishbone

Front brakesventilated disc
