Lexus ES 2003–2006

4 generation [restyling](MCV30)

General information

Number of doors4

Car classE

CountryJapan

Steering wheel positionLeft

At a glance

Engine2994 cm3 Gasoline

Power210 hp

GearboxAutomatic

Origin

Japan

Trim

3.0 AT (210 hp)3.3 AT (228 PS)

Specifications

Engine

Compression ratio10.5

Max power (kW)154 kW

Engine model1mz-fe

Engine code1MZ-FE

Engine power209 PS

Engine power210 hp

Maximum torque299 N*m

Capacity2994 cm3

Valves per cylinder4

Turnover of maximum torque4400 RPM

Max power at RPM5800 RPM

Number of cylinders6

Stroke cycle83.0 mm

Cylinder bore87.5 mm

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, longitudinal

Engine typeGasoline

Boost typenone

Cylinder layoutV-type

Bodywork

Height1455 mm

Back track width1535 mm

Front track width1545 mm

Clearance155 mm

Curb weight1560 kg

Width1810 mm

Wheel size215/55 R17, 215/60 R16

Wheelbase2720 mm

Min trunk capacity410 l

Length4855 mm

Number of seater5

Disc size6.5x16 ET50, 7x17 ET50

Pitch Circle DiameterDIA60.1 5x114.3 mm

Body typeSedan

Gearbox and handling

Number of gear5

Gearbox typeAutomatic

Drive wheelsFront wheel drive

Operating characteristics

City driving fuel consumption per 100 km11.2 l

Max speed225 km/h

CO2 emissions242 g/km

Fuel tank capacity70 l

Acceleration (0-100 km/h)8.1 s

Highway driving fuel consumption per 100 km8.1 l

Fuel95

Mixed driving fuel consumption per 100 km9.8 l

Emission standardsEuro 4

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
