Kia Ceed 2012–2015
2 generation (JD)General information
Number of doors5
Car classC
Steering wheel positionLeft
CountrySouth Korea
At a glance
Engine1396 cm3 Gasoline
Power100 hp
GearboxManual
Origin
South Korea
South KoreaSpecifications
Engine
Engine power100 hp
Compression ratio10.5
Maximum torque137 N*m
Capacity1396 cm3
Number of cylinders4
Valves per cylinder4
Turnover of maximum torque4200 RPM
Max power at RPM5500 RPM
Max power (kW)73 kW
Stroke cycle74.99 mm
Cylinder bore77.0 mm
Engine power99 PS
Injection typedistributed injection (multipoint)
Timing beltDOHC
Engine placementFront, transverse
Engine codeG4FA
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Bodywork
Curb weight1305 kg
Height1485 mm
Clearance150 mm
Front track width1549 mm
Back track width1557 mm
Max trunk capacity1642 l
Width1780 mm
Full weight1840 kg
Wheel size195/65 R15, 205/55 R16
Wheelbase2650 mm
Length4505 mm
Number of seater5
Min trunk capacity528 l
Disc size6.5x16 ET50, 6x15 ET46
Pitch Circle DiameterDIA67.1 5x114.3 mm
Body typeWagon
Gearbox and handling
Number of gear6
Drive wheelsFront wheel drive
Gearbox typeManual
Operating characteristics
Acceleration (0-100 km/h)13.5 s
CO2 emissions148 g/km
Max speed180 km/h
Fuel tank capacity53 l
Highway driving fuel consumption per 100 km5.3 l
Mixed driving fuel consumption per 100 km6.6 l
City driving fuel consumption per 100 km8.8 l
Fuel95
Emission standardsEuro 4
Suspension and brakes
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring
Front brakesventilated disc
