Hyundai XG 1998–2003

1 generation (XG)
General information
Number of doors4
Car classE
Steering wheel positionLeft
CountrySouth Korea
At a glance
Engine2351 cm3 Gasoline
Power137 hp
GearboxManual
OriginSouth Korea
Trim
2.4 MT (139 PS)2.5 AT (163 PS)2.5 MT (163 PS)3.0 AT (188 PS)3.0 AT (192 PS)3.0 AT (194 hp)3.5 AT (194 hp)3.5 AT (197 hp)

Specifications

Engine
Stroke cycle100 mm
Max power (kW)102 kW
Compression ratio11.5
Engine power137 hp
Engine power139 PS
Maximum torque192 N*m
Capacity2351 cm3
Turnover of maximum torque2500 RPM
Number of cylinders4
Valves per cylinder4
Max power at RPM5500 RPM
Cylinder bore86.5 mm
Injection typedistributed injection (multipoint)
Timing beltDOHC
Engine placementFront, transverse
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Presence of intercoolerPresent
Bodywork
Height1420 mm
Rear track1530 mm
Back track width1530 mm
Front track1540 mm
Front track width1540 mm
Ground clearance160 mm
Clearance160 mm
Width1821 mm
Curb weight1865 kg
Wheel size205/65 R15
Full weight2455 kg
Wheelbase2750 mm
Min trunk capacity411 l
Max trunk capacity453 l
Length4859 mm
Number of seater5
Payload566 kg
Pitch Circle DiameterDIA67.1 5x114.3 mm
Body typeSedan
Gearbox and handling
Turning circle11 m
Number of gear5
Drive wheelsFront wheel drive
Gearbox typeManual
Operating characteristics
Mixed driving fuel consumption per 100 km10.4 l
City driving fuel consumption per 100 km13.0 l
Max speed170 km/h
Fuel tank capacity70 l
Highway driving fuel consumption per 100 km7.0 l
Acceleration (0-100 km/h)9.1 s
Fuel92
Emission standardsEURO III
Cruising rangefrom 540 to 1 000 km
Suspension and brakes
Front brakesDisc
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
