Hyundai Grandeur 2009–2011

4 generation [restyling] (TG)

General information

Number of doors4

Car classE

Steering wheel positionLeft

CountrySouth Korea

At a glance

Engine2188 cm3 Diesel

Power148 hp

GearboxAutomatic

Origin

South Korea

Trim

2.2 AT (150 PS)2.4 AT (179 PS)2.7 AT (192 PS)2.7 AT (195 hp)3.3 AT (235 PS)3.3 AT (259 hp)

Specifications

Engine

Max power (kW)110 kW

Engine power148 hp

Engine power150 PS

Compression ratio17.3

Turnover of maximum torque1800 RPM

Capacity2188 cm3

Maximum torque335 N*m

Number of cylinders4

Valves per cylinder4

Max power at RPM4000 RPM

Cylinder bore87.0 mm

Stroke cycle92.0 mm

Injection typeCommon rail (diesel)

Engine codeD4EB

Engine modelD4EB

Engine typeDiesel

Timing beltDOHC

Engine placementFront, transverse

Cylinder layoutinline

Boost typeTurbocharged

Bodywork

Height1490 mm

Back track width1565 mm

Front track width1580 mm

Clearance162 mm

Curb weight1792 kg

Width1850 mm

Wheelbase2780 mm

Length4895 mm

Number of seater5

Min trunk capacity523 l

Body typeSedan

Gearbox and handling

Number of gear5

Gearbox typeAutomatic

Drive wheelsFront wheel drive

Operating characteristics

City driving fuel consumption per 100 km10.4 l

Acceleration (0-100 km/h)11.4 s

Max speed202 km/h

Highway driving fuel consumption per 100 km6.4 l

Fuel tank capacity75 l

Mixed driving fuel consumption per 100 km7.9 l

Fueldiesel

Emission standardsEuro 4

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
