Ford Ranger 2002–2006

3 generation (PE) [restyling]

At a glance

Engine2953 cm3 Diesel

Power156 hp

GearboxAutomatic

OriginN/A

Series

Double Cab pickup 4-doors Rap Cab pickup 2-doors Single Cab pickup 2-doors

Trim

3.0 TD AT 4x4 (156 hp)3.0 TD MT (156 hp)3.0 TD MT 4x4 (156 hp)3.0 TD MT 4x4 Chassis (156 hp)3.0 TD MT Chassis (156 hp)

Specifications

Engine

Stroke cycle102 mm

Max power (kW)116 kW

Engine power156 hp

Engine power158 PS

Capacity2953 cm3

Maximum torque380 N*m

Number of cylinders4

Valves per cylinder4

Cylinder bore96 mm

Injection typeCommon Rail

Engine typeDiesel

Cylinder layoutInline

Presence of intercoolerPresent

Turnover of maximum torqueto 1 800 RPM

Max power at RPMto 3 200 RPM

Boost typeTurbo

Bodywork

Payload1075 kg

Front/rear axle load1430/1850 kg

Rear track1440 mm

Front track1445 mm

Height1743 mm

Cargo compartment (Length x Width x Height)1753x1456x465 mm

Width1788 mm

Curb weight1967 kg

Ground clearance207 mm

Wheelbase3000 mm

Full weight3042 kg

Number of seater4

Trailer load (with brakes)4875 kg

Length5173 mm

Body typePickup

Gearbox and handling

Turning circle12.6 m

Number of gear5

Gearbox typeAutomatic

Drive wheelsFour wheel drive (4WD)

Operating characteristics

Fuel tank capacity70 l

Fueldiesel

Suspension and brakes

Rear brakesdrum

Front suspensionIndependent, Double wishbone, Stabilizer bar

Back suspensionSpring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.

No grades recorded for this trim yet.
