Ford Kuga 2016–2019

2 generation (C520) [restyling]
General information
Number of doors5
Car classC
Steering wheel positionLeft
CountryUSA
At a glance
Engine1498 cm3 Gasoline
Power148 hp
GearboxAutomatic
OriginUnited States
Trim
1.5 (150 hp), gasoline, Automatic transmission, Four-wheel drive (4WD)1.5 (182 hp), gasoline, Automatic transmission, Four-wheel drive (4WD)1.5 AMT (120 hp)1.5 EcoBoost AT AWD (150 PS)1.5 EcoBoost AT AWD (182 PS)1.5 MT (120 hp)1.5 MT (150 hp)2.0 AMT (120 hp)2.0 AMT (150 hp)2.0 AMT (180 hp)2.0 AT (230 hp)2.0 AT (242 hp)2.0 MT (120 hp)2.0 MT (150 hp)2.0 MT (180 hp)2.5 (150 PS), gasoline, Automatic transmission, front drive2.5 AT (150 PS)

Specifications

Engine
Compression ratio10
Max power (kW)110 kW
Engine power148 hp
Capacity1498 cm3
Engine power150 PS
Maximum torque240 N*m
Number of cylinders4
Valves per cylinder4
Turnover of maximum torque4000 RPM
Max power at RPM6000 RPM
Stroke cycle76.4 mm
Cylinder bore79.0 mm
Injection typedirect injection (direct)
Timing beltDOHC
Engine placementFront, transverse
Engine typeGasoline
Cylinder layoutinline
Engine codeM8MA
Presence of intercoolerPresent
Boost typeTurbocharged
Bodywork
Front track1563 mm
Rear track1565 mm
Front track width1573 mm
Back track width1583 mm
Max trunk capacity1603 l
Curb weight1686 kg
Height1694 mm
Width1838 mm
Ground clearance200 mm
Clearance200 mm
Wheel size235/50 R18, 235/55 R17
Wheelbase2690 mm
Length4531 mm
Min trunk capacity456 l
Number of seater5
Body typeCrossover
Pitch Circle DiameterDIA63.4 5x108 mm
Gearbox and handling
Turning circle11.1 m
Number of gear6
Drive wheelsAll wheel drive (AWD)
Gearbox typeAutomatic
Operating characteristics
City driving fuel consumption per 100 km10.7 l
Acceleration (0-100 km/h)10.7 s
Max speed212 km/h
Fuel tank capacity60 l
Highway driving fuel consumption per 100 km6.4 l
Mixed driving fuel consumption per 100 km8.0 l
Fuel95
Emission standardsEuro 6
Cruising rangefrom 610 to 1 020 km
Suspension and brakes
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring
Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
