Ford Fusion (North America) 2006–20012

1 generation (CD3)

General information

Number of doors4

Car classD

Steering wheel positionLeft

CountryUSA

At a glance

Engine2261 cm3 Gasoline

Power160 hp

GearboxAutomatic

Origin

United States

Trim

2.3 AT (162 PS)2.3 MT (162 PS)3.0 AT (212 PS)

Specifications

Engine

Max power (kW)119 kW

Engine power160 hp

Engine power162 PS

Maximum torque203 N*m

Capacity2261 cm3

Number of cylinders4

Valves per cylinder4

Turnover of maximum torque4000 RPM

Max power at RPM6500 RPM

Cylinder bore87.5 mm

Stroke cycle94 mm

Compression ratio9.7

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Engine codeSEBA

Engine modelSEBA

Bodywork

Height1417 mm

Clearance152 mm

Back track width1557 mm

Front track width1565 mm

Width1834 mm

Wheel size205/60 R16

Wheelbase2728 mm

Min trunk capacity448 l

Length4831 mm

Number of seater5

Pitch Circle DiameterDIA67.1 5x114.3 mm

Body typeSedan

Gearbox and handling

Number of gear5

Gearbox typeAutomatic

Drive wheelsFront wheel drive

Operating characteristics

Mixed driving fuel consumption per 100 km10.2 l

City driving fuel consumption per 100 km11.8 l

Fuel tank capacity68 l

Highway driving fuel consumption per 100 km8.4 l

Fuel92

Acceleration (0-100 km/h)9.3 s

Suspension and brakes

Front brakesDisc

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
