Dodge Caravan 1995–2000

3 generation (NS)
General information
Number of doors5
Steering wheel positionLeft
Car classM
CountryUSA
At a glance
Engine2972 cm3 Gasoline
Power150 hp
GearboxAutomatic
OriginUnited States
Series
Grand minivan 5-doorsMinivanMinivan 5-doors
Trim
2.4 AT (152 PS)2.4 AT AWD (152 PS)2.4 MT (152 PS)2.4 MT AWD (152 PS)2.5 MT (116 PS)3.0 AT (152 PS)3.0 AT AWD (152 PS)3.3 AT (158 PS)3.3 AT AWD (158 PS)3.8 AT (166 PS)3.8 AT 4WD (166 hp)3.8 AT AWD (166 PS)

Specifications

Engine
Max power (kW)112 kW
Engine power150 hp
Engine power152 PS
Valves per cylinder2
Maximum torque239 N*m
Capacity2972 cm3
Turnover of maximum torque4000 RPM
Max power at RPM5200 RPM
Number of cylinders6
Stroke cycle76.0 mm
Compression ratio8.9
Cylinder bore91.1 mm
Injection typedistributed injection (multipoint)
Engine placementFront, transverse
Engine typeGasoline
Boost typenone
Timing beltOHC
Cylinder layoutV-type
Bodywork
Ground clearance140 mm
Clearance140 mm
Front track1600 mm
Front track width1600 mm
Rear track1626 mm
Back track width1626 mm
Curb weight1669 kg
Height1740 mm
Width1920 mm
Wheel size215/60 R16, 215/65 R15
Full weight2454 kg
Wheelbase2878 mm
Max trunk capacity4140 l
Min trunk capacity450 l
Length4733 mm
Number of seater7
Pitch Circle DiameterDIA71.6 5x114.3 mm
Body typeMinivan
Gearbox and handling
Number of gear3
Gearbox typeAutomatic
Drive wheelsFront wheel drive
Operating characteristics
Mixed driving fuel consumption per 100 km11.2 l
Acceleration (0-100 km/h)11.7 s
City driving fuel consumption per 100 km12.4 l
Max speed170 km/h
Fuel tank capacity75 l
Highway driving fuel consumption per 100 km9.0 l
Fuel92
Cruising rangefrom 600 to 770 km
Suspension and brakes
Back suspensionDependent, spring
Rear brakesdrum
Front suspensionIndependent, spring
Front brakesventilated disc
