Dodge WC series 1942–1945

4 generation (G-502 / T214)
General information
Number of doors5
Car classJ
CountryUSA
At a glance
Engine3772 cm3 Gasoline
Power91 hp
GearboxManual
OriginUnited States
Series
SUV opened WC-51SUV opened WC-52SUV opened WC-57
Trim
3.8 MT 4WD (92 PS)3.8 MT AWD (92 PS)

Specifications

Engine
Stroke cycle117.5 mm
Turnover of maximum torque1200 kW
Valves per cylinder2
Maximum torque244 N*m
Max power at RPM3200 RPM
Capacity3772 cm3
Number of cylinders6
Compression ratio6.7
Max power (kW)68 kW
Cylinder bore82.6 mm
Engine power91 hp
Engine power92 PS
Injection typecarburetor
Engine placementFront, longitudinal
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Bodywork
Back track width1650 mm
Front track width1670 mm
Width2000 mm
Height2070 mm
Wheelbase2490 mm
Curb weight2560 kg
Clearance273 mm
Full weight3360 kg
Length4460 mm
Number of seater5
Body typeCrossover
Gearbox and handling
Number of gear4
Drive wheelsfull
Gearbox typeManual
Operating characteristics
Fuel tank capacity115 l
Fuel76
Max speed87 km/h
Suspension and brakes
Front suspensionDependent, spring
Back suspensionDependent, spring
Front brakesdrum
Rear brakesdrum
