Dodge Diplomat 1977–1979

1 generation (M-body)
General information
Number of doors2
Car classE
Steering wheel positionLeft
CountryUSA
At a glance
Engine3682 cm3 Gasoline
Power84 hp
GearboxAutomatic
OriginUnited States
Series
CoupeSedanwagon 5 doors
Trim
3.7 AT (101 PS)3.7 AT (112 hp)3.7 AT (86 PS)3.7 AT (91 PS)3.7 MT (101 PS)3.7 MT (112 hp)5.2 AT (122 PS)5.2 AT (132 PS)5.2 AT (137 PS)5.2 AT (142 hp)5.2 AT (147 PS)5.2 AT (157 hp)5.2 AT (167 PS)5.2 MT (142 hp)5.9 AT (152 PS)5.9 AT (157 hp)5.9 AT (172 hp)5.9 AT (193 PS)5.9 AT (198 hp)

Specifications

Engine
Stroke cycle104.8 mm
Turnover of maximum torque1600 RPM
Valves per cylinder2
Maximum torque224 N*m
Max power at RPM3600 RPM
Capacity3682 cm3
Number of cylinders6
Max power (kW)63 kW
Engine power84 hp
Compression ratio8.4
Engine power86 PS
Cylinder bore86.4 mm
Injection typecarburetor
Engine modelChrysler Slant-6 225
Engine placementFront, longitudinal
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Timing beltOHV
Engine codeSlant-6 225
Bodywork
Clearance122 mm
Height1354 mm
Back track width1486 mm
Curb weight1500 kg
Front track width1524 mm
Width1867 mm
Wheelbase2863 mm
Min trunk capacity465 l
Number of seater5
Length5184 mm
Body typeCoupe
Gearbox and handling
Number of gear3
Gearbox typeAutomatic
Drive wheelsRear wheel drive
Operating characteristics
Highway driving fuel consumption per 100 km10.7 l
Mixed driving fuel consumption per 100 km11.8 l
City driving fuel consumption per 100 km13.1 l
Acceleration (0-100 km/h)21.0 s
Fuel tank capacity74 l
Suspension and brakes
Back suspensionDependent, spring
Front brakesDisc
Rear brakesdrum
Front suspensionIndependent, Torsion

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
