Chevrolet Suburban 1967–1972
6 generation (C/K Series)At a glance
Engine3859 cm3 Gasoline
Power135 hp
GearboxAutomatic
OriginN/A
Series
Trim
3.9 3MT Synchro-mesh (135 hp)3.9 3MT Synchro-mesh Heavy Duty (135 hp)3.9 4MT Synchro-mesh (135 hp)3.9 4MT Synchro-mesh 4WD (135 hp)3.9 AT Powerglide (135 hp)3.9 Economy 3MT Synchro-mesh (110 hp)4.6 3MT Synchro-mesh (160 hp)4.6 3MT Synchro-mesh Heavy Duty (160 hp)4.6 4MT Synchro-mesh (160 hp)4.6 AT Powerglide (160 hp)
Specifications
Engine
Stroke cycle100.3 mm
Max power (kW)101 kW
Engine power135 hp
Engine power137 PS
Valves per cylinder2
Maximum torque294 N*m
Capacity3859 cm3
Number of cylinders6
Cylinder bore90.5 mm
Injection typecarburetor
Engine typeGasoline
Cylinder layoutInline
Turnover of maximum torqueto 2 000 RPM
Max power at RPMto 4 000 RPM
Bodywork
Rear track1550 mm
Front track1604 mm
Height1917 mm
Ground clearance195 mm
Width2017 mm
Full weight2359 kg
Wheelbase2921 mm
Length5066 mm
Payload590 kg
Number of seater8
Body typeCrossover
Gearbox and handling
Turning circle12.5 m
Number of gear2
Gearbox typeAutomatic
Drive wheelsRear wheel drive
Operating characteristics
Fuel tank capacity75.7 l
FuelGasoline
Suspension and brakes
Back suspensionDependent, spring
Front brakesdrum
Rear brakesdrum
Front suspensionIndependent, Multi wishbone, Stabilizer bar
Grades & features
Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
No grades recorded for this trim yet.
