Chevrolet Orlando 2010–2018

1 generation (J309)
General information
Number of doors5
Steering wheel positionLeft
Car classM
CountryUSA
At a glance
Engine1362 cm3 Gasoline
Power140 hp
GearboxManual
OriginUnited States
Trim
1.4 Turbo MT (140 hp)1.6 AT (134 hp)1.8 AT (141 PS)1.8 MT (141 PS)2.0 LPG AT (138 hp)2.0 VCDi AT (163 PS)2.0 VCDi MT (130 hp)2.0 VCDi MT (163 hp)2.4 AT (176 hp)2.4 MT (176 hp)

Specifications

Engine
Max power (kW)104 kW
Capacity1362 cm3
Engine power140 hp
Engine power141 PS
Turnover of maximum torque1850 RPM
Maximum torque200 N*m
Number of cylinders4
Valves per cylinder4
Cylinder bore72.5 mm
Stroke cycle82.5 mm
Compression ratio9.5
Injection typedirect injection (direct)
Timing beltDOHC
Engine placementFront, transverse
Engine typeGasoline
Cylinder layoutinline
Engine codeLUV
Max power at RPMto 4 900 RPM
Boost typeTurbocharged
Bodywork
Ground clearance140 mm
Clearance140 mm
Front track1584 mm
Front track width1584 mm
Rear track1588 mm
Back track width1588 mm
Height1633 mm
Curb weight1674 kg
Width1836 mm
Wheel size215/55 R17, 235/45 R18, 215/60 R16
Full weight2179 kg
Wheelbase2761 mm
Min trunk capacity454 l
Length4652 mm
Max trunk capacity466 l
Payload565 kg
Number of seater7
Pitch Circle DiameterDIA70.1 5x115 mm
Body typeMinivan
Gearbox and handling
Turning circle11.3 m
Number of gear6
Drive wheelsFront wheel drive
Gearbox typeManual
Operating characteristics
Acceleration (0-100 km/h)11.0 s
Max speed200 km/h
Highway driving fuel consumption per 100 km5.4 l
Fuel tank capacity64 l
Mixed driving fuel consumption per 100 km6.4 l
City driving fuel consumption per 100 km7.6 l
Fuel95
Emission standardsEuro 5
Cruising rangefrom 840 to 1 190 km
Suspension and brakes
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring
Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.

No grades recorded for this trim yet.
