Chevrolet Captiva 2015–2018

1 generation (C100 / CG) [3th restyling]

General information

Number of doors5

Car classD

Steering wheel positionLeft

CountryUSA

At a glance

Engine1998 cm3 Diesel

Power161 hp

GearboxAutomatic

Origin

United States

Trim

2.0 AT 4WD (163 PS)2.4 AT 4WD (167 PS)2.4 MT (167 PS)2.4 MT 4WD (167 PS)3.0 AT 4WD (249 PS)

Specifications

Engine

Max power (kW)120 kW

Engine power161 hp

Engine power163 PS

Compression ratio16.3

Capacity1998 cm3

Turnover of maximum torque2000 RPM

Max power at RPM3800 RPM

Number of cylinders4

Valves per cylinder4

Maximum torque400 N*m

Cylinder bore86 mm

Stroke cycle86 mm

Injection typeCommon rail (diesel)

Engine typeDiesel

Timing beltDOHC

Engine placementFront, transverse

Cylinder layoutinline

Boost typeTurbocharged

Bodywork

Front track width1569 mm

Back track width1576 mm

Height1727 mm

Width1849 mm

Curb weight1920 kg

Clearance200 mm

Wheel size215/70 R16, 235/50 R19, 235/55 R18, 235/60 R17

Wheelbase2707 mm

Length4673 mm

Min trunk capacity477 l

Number of seater5, 7

Disc size6.5x16 ET46, 7x17 ET46, 7x18 ET45, 7x19 ET45

Max trunk capacity942 l

Body typeCrossover

Pitch Circle DiameterDIA70.1 5x115 mm

Gearbox and handling

Number of gear6

Gearbox typeAutomatic

Drive wheelsFront wheel drive

Operating characteristics

Acceleration (0-100 km/h)11.3 s

Max speed182 km/h

CO2 emissions198 g/km

Fuel tank capacity65 l

Mixed driving fuel consumption per 100 km7.4 l

Fueldiesel

Emission standardsEuro 5

Suspension and brakes

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc

Rear brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
