Chery Tiggo 4 2017–2019

1 generation (T17)

General information

Number of doors5

Car classB

CountryChina

Steering wheel positionLeft

At a glance

Engine1971 cm3 Gasoline

Power121 hp

GearboxContinuously variable transmission (CVT)

Origin

China

Trim

1.5 AMT (147 hp)1.5 MT (147 hp)2.0 (122 hp) Comfort CVT 2.0 (122 hp) gasoline, MT, front drive 2.0 (122 PS) gasoline, variator (CVT), front drive 2.0 CVT (122 PS)2.0 MT (122 hp)

Specifications

Engine

Compression ratio10.5

Engine power121 hp

Engine power122 PS

Maximum torque180 N*m

Capacity1971 cm3

Number of cylinders4

Valves per cylinder4

Turnover of maximum torque4000 RPM

Max power at RPM5500 RPM

Cylinder bore83.5 mm

Stroke cycle90 mm

Max power (kW)90 kW

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Engine modelSQRD4G20

Engine codeSQRD4G20

Bodywork

Max trunk capacity1100 l

Curb weight1494 kg

Front track1550 mm

Rear track1550 mm

Front track width1550 mm

Back track width1550 mm

Height1647 mm

Width1830 mm

Ground clearance190 mm

Clearance190 mm

Wheel size215/55 R18, 215/60 R17

Wheelbase2610 mm

Min trunk capacity340 l

Length4298 mm

Number of seater5

Body typeCrossover

Pitch Circle DiameterDIA60.1 5x108 mm

Gearbox and handling

Gearbox typeContinuously variable transmission (CVT)

Drive wheelsFront wheel drive

Operating characteristics

City driving fuel consumption per 100 km11.2 l

Max speed174 km/h

Fuel tank capacity57 l

Highway driving fuel consumption per 100 km6.4 l

Mixed driving fuel consumption per 100 km8.2 l

Fuel95

Emission standardsEuro 5

Cruising rangefrom 510 to 890 km

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc
