BMW 2 series Active Tourer 2014–2018

1 generation (F45)

At a glance

Engine1499 cm3 Gasoline

Power136 hp

GearboxAutomatic

OriginN/A

Trim

1.5 AT (116 hp)1.5 AT (136 PS)1.5 AT (224 hp)1.5 MT (102 hp)1.5 MT (116 hp)1.5 MT (136 PS)1.5 MT (95 hp)2.0 AT (150 hp)2.0 AT (190 hp)2.0 AT (192 hp)2.0 AT (231 hp)2.0 MT (150 hp)2.0 MT (190 hp)2.0 MT (192 hp)214d MT Gran (95 hp)216d MT (116 hp)216d MT Gran (116 hp)216d Steptronic (116 hp)216d Steptronic Gran (116 hp)216i MT (102 hp)216i MT Gran (102 hp)218d MT (150 hp)218d MT Gran (150 hp)218d MT xDrive (150 hp)218d MT xDrive Gran (150 hp)218d Steptronic (150 hp)218d Steptronic Gran (150 hp)218d Steptronic xDrive (150 hp)218d Steptronic xDrive Gran (150 hp)218i MT (136 hp)218i MT Gran (136 hp)218i Steptronic (136 hp)218i Steptronic Gran (136 hp)220d MT (190 hp)220d MT Gran (190 hp)220d Steptronic (190 hp)220d Steptronic Gran (190 hp)220d Steptronic xDrive Gran (190 hp)220d xDrive Steptronic (190 hp)220i MT (192 hp)220i MT Gran (192 hp)220i Steptronic (192 hp)220i Steptronic Gran (192 hp)225i Steptronic (231 hp)225i xDrive Steptronic (231 hp)225xe Steptronic (224 hp)

Specifications

Engine

Max power (kW)101 kW

Engine power136 hp

Engine power137 PS

Capacity1499 cm3

Maximum torque220 N*m

Number of cylinders3

Valves per cylinder4

Cylinder bore82 mm

Stroke cycle94.6 mm

Injection typedirect injection

Turnover of maximum torquefrom 1 250 to 4 300 RPM

Engine typeGasoline

Cylinder layoutInline

Presence of intercoolerPresent

Max power at RPMto 4 400 RPM

Boost typeTurbo

Bodywork

Front/rear axle load1015/930 kg

Curb weight1360 kg

Max trunk capacity1510 l

Height1555 mm

Front track1561 mm

Rear track1562 mm

Ground clearance165 mm

Width1800 mm

Full weight1910 kg

Wheelbase2670 mm

Trailer load (with brakes)3210 kg

Length4342 mm

Min trunk capacity468 l

Number of seater5

Payload625 kg

Body typeMinivan

Gearbox and handling

Turning circle11.3 m

Number of gear6

Gearbox typeAutomatic

Drive wheelsFront wheel drive

Operating characteristics

Max speed205 km/h

Highway driving fuel consumption per 100 km4.4 l

Fuel tank capacity51 l

Mixed driving fuel consumption per 100 km5.1 l

City driving fuel consumption per 100 km6.3 l

Acceleration (0-100 km/h)9.2 s

Fuel98, 95, 92

Emission standardsEURO VI

Cruising rangefrom 810 to 1 160 km

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, McPherson Struts, Stabilizer bar

Back suspensionIndependent, Multi wishbone, Stabilizer bar

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
