Toyota Vitz 2014–2017

3 generation (XP130) [restyling]
General information
Number of doors5
Car classB
CountryJapan
Steering wheel positionRight
At a glance
Engine996 cm3 Gasoline
Power68 hp
GearboxContinuously variable transmission (CVT)
OriginJapan
Series
Hatchback 3 doors GRMNHatchback 5 doors
Trim
1.0 CVT (69 PS)1.3 CVT 4WD (95 PS)1.3 CVT (99 PS)1.5 CVT (109 PS)1.5 CVT (74 hp)1.5 MT (109 PS)

Specifications

Engine
Compression ratio10.5
Engine code1KR-FE
Engine model1KR-FE
Number of cylinders3
Turnover of maximum torque3600 RPM
Valves per cylinder4
Max power (kW)51 kW
Max power at RPM6000 RPM
Engine power68 hp
Engine power69 PS
Cylinder bore71 mm
Stroke cycle83.9 mm
Maximum torque92 N*m
Capacity996 cm3
Injection typedistributed injection (multipoint)
Timing beltDOHC
Engine placementFront, transverse
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Bodywork
Full weight1245 kg
Clearance140 mm
Back track width1470 mm
Front track width1485 mm
Height1530 mm
Wheel size165/70 R14
Width1695 mm
Wheelbase2510 mm
Length3885 mm
Number of seater5
Disc size5x14 ET39
Curb weight970 kg
Pitch Circle DiameterDIA54.1 4x100 mm
Body typeHatchback
Gearbox and handling
Gearbox typeContinuously variable transmission (CVT)
Drive wheelsFront wheel drive
Operating characteristics
Acceleration (0-100 km/h)15.3 s
Max speed170 km/h
Fuel tank capacity42 l
Mixed driving fuel consumption per 100 km4.6 l
Fuel95
Emission standardsEuro 5
Suspension and brakes
Rear brakesdrum
Front suspensionIndependent, spring
Back suspensionSemi-independent, torsion
Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
