Toyota Verso 2012–2018
1 generation (AR20) [restyling]General information
Number of doors5
CountryJapan
Steering wheel positionLeft
Car classM
At a glance
Engine1598 cm3 Gasoline
Power130 hp
GearboxManual
Origin
Japan
JapanSpecifications
Engine
Compression ratio10.7
Engine power130 hp
Engine power132 PS
Capacity1598 cm3
Maximum torque160 N*m
Engine code1ZR-FAE
Number of cylinders4
Valves per cylinder4
Turnover of maximum torque4400 RPM
Max power at RPM6400 RPM
Stroke cycle78.5 mm
Cylinder bore80.5 mm
Max power (kW)97 kW
Injection typedistributed injection (multipoint)
Timing beltDOHC
Engine placementFront, transverse
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Bodywork
Front/rear axle load1025/1080 kg
Ground clearance145 mm
Clearance145 mm
Curb weight1505 kg
Front track1535 mm
Front track width1535 mm
Rear track1545 mm
Back track width1545 mm
Height1620 mm
Max trunk capacity1696 l
Width1790 mm
Wheel size205/60 R16
Full weight2125 kg
Wheelbase2780 mm
Trailer load (with brakes)3425 kg
Min trunk capacity446 l
Length4460 mm
Number of seater5, 7
Payload630 kg
Pitch Circle DiameterDIA60.1 5x114.3 mm
Body typeMinivan
Gearbox and handling
Turning circle10.8 m
Number of gear6
Drive wheelsFront wheel drive
Gearbox typeManual
Operating characteristics
Acceleration (0-100 km/h)11.7 s
CO2 emissions154 g/km
Max speed185 km/h
Highway driving fuel consumption per 100 km5.6 l
Fuel tank capacity60 l
Mixed driving fuel consumption per 100 km6.6 l
City driving fuel consumption per 100 km8.3 l
Fuel95
Emission standardsEuro 4
Cruising rangefrom 720 to 1 070 km
Suspension and brakes
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionSemi-dependent, spring
Front brakesventilated disc
