Toyota Vellfire 2011–2015

1 generation (AH20) [restyling]

General information

Number of doors5

CountryJapan

Car classM

Steering wheel positionRight

At a glance

Engine2362 cm3 Gasoline

Power168 hp

GearboxContinuously variable transmission (CVT)

Origin

Japan

Trim

2.4 CVT 2WD (170 hp)2.4 CVT 4WD (170 PS)2.4 Hybrid CVT 4WD (150 PS)3.5 AT 2WD (280 hp)3.5 AT 4WD (280 PS)

Specifications

Engine

Max power (kW)125 kW

Engine power168 hp

Engine power170 PS

Maximum torque224 N*m

Capacity2362 cm3

Engine model2az-fe

Engine code2AZ-FE

Number of cylinders4

Valves per cylinder4

Turnover of maximum torque4000 RPM

Max power at RPM6000 RPM

Cylinder bore88.5 mm

Stroke cycle96 mm

Compression ratio9.8

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Bodywork

Front track1580 mm

Front track width1580 mm

Rear track1585 mm

Back track width1585 mm

Clearance160 mm

Ground clearance170 mm

Width1830 mm

Height1890 mm

Wheel size215/60 R17, 215/65 R16, 235/50 R18

Curb weight2330 kg

Wheelbase2950 mm

Length4850 mm

Number of seater6, 7

Pitch Circle DiameterDIA60.1 5x114.3 mm

Body typeMinivan

Gearbox and handling

Turning circle11.4 m

Drive wheelsAll wheel drive (AWD)

Gearbox typeContinuously variable transmission (CVT)

Operating characteristics

Acceleration (0-100 km/h)11.3 s

Max speed170 km/h

Fuel tank capacity65 l

Mixed driving fuel consumption per 100 km8.8 l

Fuel95

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionSemi-independent, torsion

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
