Toyota Tercel 1990–1992

4 generation (L40 / EL41 / EL43 / EL45 / NL40)
General information
Number of doors4
Car classB
CountryJapan
Steering wheel positionLeft/Right
At a glance
Engine1497 cm3 Gasoline
Power100 hp
GearboxAutomatic
OriginJapan
Series
HatchbackSedanSedan 2 doors
Trim
1.3 AT (100 hp)1.3 AT (97 hp)1.3 MT (100 hp)1.3 MT (97 hp)1.5 AT (100 hp)1.5 AT (105 PS)1.5 AT (115 hp)1.5 AT AWD (100 hp)1.5 MT (100 hp)1.5 MT (105 PS)1.5 MT (115 hp)1.5 MT AWD (100 hp)1.5 TD AT (67 PS)1.5 TD MT (67 PS)

Specifications

Engine
Engine power100 hp
Engine power101 PS
Maximum torque126 N*m
Capacity1497 cm3
Turnover of maximum torque3000 RPM
Number of cylinders4
Valves per cylinder4
Engine code5E-FE
Max power at RPM6200 RPM
Cylinder bore74 mm
Max power (kW)74 kW
Stroke cycle87 mm
Compression ratio9.4
Injection typedistributed injection (multipoint)
Timing beltDOHC
Engine placementFront, transverse
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Bodywork
Curb weight1020 kg
Full weight1155 kg
Back track width1380 mm
Height1385 mm
Front track width1395 mm
Front track1400 mm
Rear track1430 mm
Ground clearance160 mm
Clearance160 mm
Width1660 mm
Wheel size175/65 R14, 175/70 R13
Wheelbase2380 mm
Length4110 mm
Number of seater5
Pitch Circle DiameterDIA54.1 4x100 mm
Body typeSedan
Gearbox and handling
Number of gear4
Turning circle9 m
Gearbox typeAutomatic
Drive wheelsFront wheel drive
Operating characteristics
Acceleration (0-100 km/h)10.3 s
Fuel tank capacity45 l
Mixed driving fuel consumption per 100 km7.7 l
Fuel92
Suspension and brakes
Rear brakesdrum
Front suspensionIndependent, spring
Back suspensionIndependent, spring
Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
