Toyota Succeed 2002–2014

1 generation (XP50)

At a glance

Engine1496 cm3 Gasoline

Power105 hp

GearboxAutomatic

OriginN/A

Trim

1.4 D-4D MT Van (72 PS)1.5 AT 4WD (105 hp)1.5 AT 4WD Van (105 hp)1.5 AT Van (109 hp)1.5 AT Wagon (109 PS)1.5 MT 4WD Van (105 hp)1.5 MT Van (109 PS)

Specifications

Engine

Engine power105 hp

Engine power106 PS

Maximum torque138 N*m

Capacity1496 cm3

Number of cylinders4

Valves per cylinder4

Cylinder bore75 mm

Max power (kW)78 kW

Stroke cycle84.7 mm

Engine typeGasoline

Cylinder layoutInline

Injection typeMulti-point fuel injection

Presence of intercoolerPresent

Turnover of maximum torqueto 4 200 RPM

Max power at RPMto 6 000 RPM

Bodywork

Curb weight1140 kg

Full weight1415 kg

Front track1450 mm

Rear track1455 mm

Height1515 mm

Ground clearance155 mm

Width1695 mm

Wheelbase2550 mm

Payload275 kg

Length4300 mm

Number of seater5

Body typeWagon

Gearbox and handling

Turning circle10.4 m

Number of gear4

Drive wheelsAll wheel drive (AWD)

Gearbox typeAutomatic

Operating characteristics

Fuel tank capacity50 l

Fuel92

Suspension and brakes

Rear brakesdrum

Back suspensionMulti wishbone, Trailing arms, Stabilizer bar

Front suspensionStrut

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.

No grades recorded for this trim yet.
