Toyota C-HR 2019–2023

1 generation (AX10/AX50) [restyling]

General information

Number of doors5

Car classB

CountryJapan

Steering wheel positionLeft/Right

At a glance

Engine1986 cm3 Gasoline

Power146 hp

GearboxContinuously variable transmission (CVT)

Origin

Japan

Trim

1.2 CVT 4WD (116 PS)1.2 CVT AWD (116 PS)1.2 MT (116 PS)1.8 AT (98 PS)2.0 AT (152 PS)2.0 CVT (148 PS)2.0 CVT (171 PS)2.0 CVT (184 PS)AT (204 PS)

Specifications

Engine

Compression ratio10.5

Max power (kW)109 kW

Engine power146 hp

Engine power148 PS

Maximum torque189 N*m

Capacity1986 cm3

Turnover of maximum torque3900 RPM

Engine model3ZR-FAE

Engine code3ZR-FAE

Number of cylinders4

Valves per cylinder4

Max power at RPM6100 RPM

Cylinder bore80.5 mm

Stroke cycle97.6 mm

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Bodywork

Curb weight1495 kg

Front track width1550 mm

Height1565 mm

Back track width1570 mm

Clearance160 mm

Width1795 mm

Full weight1960 kg

Wheel size215/60 R17, 225/50 R18

Wheelbase2640 mm

Min trunk capacity297 l

Length4360 mm

Number of seater5

Disc size6.5x17 ET45, 7x18 ET50

Body typeCrossover

Pitch Circle DiameterDIA60.1 5x114.3 mm

Gearbox and handling

Gearbox typeContinuously variable transmission (CVT)

Drive wheelsFront wheel drive

Operating characteristics

Acceleration (0-100 km/h)11.0 s

Max speed195 km/h

CO2 emissions205 g/km

Fuel tank capacity50 l

Highway driving fuel consumption per 100 km5.8 l

Mixed driving fuel consumption per 100 km6.9 l

City driving fuel consumption per 100 km8.8 l

Fuel92

Emission standardsEuro 5

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
