Toyota C-HR 2016–2019

1 generation (AX10/AX50)
General information
Number of doors5
Car classC
CountryJapan
Steering wheel positionLeft/Right
At a glance
Engine1197 cm3 Gasoline
Power115 hp
GearboxContinuously variable transmission (CVT)
OriginJapan
Trim
1.2 CVT (115 hp)1.2 CVT AWD (115 hp)1.2 MT (115 hp)1.8 CVT Hybrid (98 hp)2.0 CVT (148 hp)2.0 CVT AWD (148 PS)2.0 CVT FWD (171 hp)

Specifications

Engine
Compression ratio10
Engine power115 hp
Engine power116 PS
Capacity1197 cm3
Maximum torque185 N*m
Number of cylinders4
Valves per cylinder4
Turnover of maximum torque4000 RPM
Max power at RPM5600 RPM
Cylinder bore71.5 mm
Stroke cycle74.5 mm
Max power (kW)85 kW
Engine model8NR-FTS
Engine code8NR-FTS
Injection typedirect injection (direct)
Timing beltDOHC
Engine placementFront, transverse
Engine typeGasoline
Cylinder layoutinline
Presence of intercoolerPresent
Boost typeTurbocharged
Bodywork
Curb weight1460 kg
Front track1550 mm
Rear track1550 mm
Front track width1550 mm
Back track width1550 mm
Height1565 mm
Ground clearance160 mm
Clearance160 mm
Width1795 mm
Full weight1930 kg
Wheel size215/60 R17
Wheelbase2640 mm
Min trunk capacity297 l
Max trunk capacity377 l
Length4360 mm
Payload475 kg
Number of seater5
Body typeCrossover
Pitch Circle DiameterDIA60.1 5x114.3 mm
Gearbox and handling
Turning circle10.4 m
Drive wheelsAll wheel drive (AWD)
Gearbox typeContinuously variable transmission (CVT)
Operating characteristics
Acceleration (0-100 km/h)11.4 s
CO2 emissions143 g/km
Max speed180 km/h
Fuel tank capacity50 l
Highway driving fuel consumption per 100 km5.6 l
Mixed driving fuel consumption per 100 km6.3 l
City driving fuel consumption per 100 km7.6 l
Fuel95
Emission standardsEuro 6
Cruising rangefrom 680 to 980 km
Suspension and brakes
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring
Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
