Toyota Land Cruiser 1989–1994

5 Generation (80 Series)
General information
Number of doors5
Car classJ
CountryJapan
Steering wheel positionLeft/Right
At a glance
Engine3955 cm3 Gasoline
Power156 hp
GearboxAutomatic
OriginJapan
Trim
4.0 AT 4WD (150 PS)4.0 AT 4WD (156 hp)4.0 MT 4WD (156 hp)4.2 AT 4WD (135 PS)4.2 AT 4WD (160 PS)4.2 AT 4WD (165 PS)4.2 MT 4WD (135 PS)4.2 MT 4WD (160 PS)4.2 MT 4WD (165 PS)4.2 MT 4WD (167 PS)4.5 AT 4WD (205 PS)4.5 AT 4WD (215 PS)4.5 MT 4WD (205 PS)4.5 MT 4WD (215 PS)

Specifications

Engine
Max power (kW)114 kW
Engine power155 PS
Engine power156 hp
Turnover of maximum torque2600 RPM
Maximum torque289 N*m
Capacity3955 cm3
Engine model3f
Engine code3F-E
Valves per cylinder4
Max power at RPM4200 RPM
Number of cylinders6
Compression ratio8.1
Cylinder bore94.0 mm
Stroke cycle95.0 mm
Injection typedistributed injection (multipoint)
Engine placementFront, longitudinal
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Timing beltOHC
Bodywork
Max trunk capacity1368 l
Front track width1575 mm
Back track width1580 mm
Width1900 mm
Height1900 mm
Clearance210 mm
Wheel size215/80 R16
Curb weight2210 kg
Wheelbase2850 mm
Length4820 mm
Number of seater5, 8
Disc size6x16 ET0, 7x15 ET10, 8x16 ET0
Min trunk capacity832 l
Body typeCrossover
Pitch Circle DiameterDIA106.1 6x139.7 mm
Gearbox and handling
Number of gear4
Drive wheelsAll wheel drive (AWD)
Gearbox typeAutomatic
Operating characteristics
Acceleration (0-100 km/h)15.0 s
Max speed155 km/h
Mixed driving fuel consumption per 100 km23.8 l
Fuel92
Fuel tank capacity95 l
Suspension and brakes
Front suspensionDependent, spring
Back suspensionDependent, spring
Front brakesventilated disc
Rear brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
