Toyota Kluger 2000–2003

1 generation (XU20)

General information

Number of doors5

Car classE

CountryJapan

Steering wheel positionRight

At a glance

Engine2362 cm3 Gasoline

Power158 hp

GearboxAutomatic

Origin

Japan

Trim

2.4 AT (160 PS)2.4 AT 4WD (160 PS)3.0 AT (220 PS)3.0 AT 4WD (220 PS)

Specifications

Engine

Max power (kW)118 kW

Engine power158 hp

Engine power160 PS

Maximum torque221 N*m

Capacity2362 cm3

Engine code2AZ-FE

Number of cylinders4

Valves per cylinder4

Turnover of maximum torque4000 RPM

Max power at RPM5600 RPM

Cylinder bore88.5 mm

Compression ratio9.6

Stroke cycle96.0 mm

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Bodywork

Curb weight1540 kg

Back track width1555 mm

Front track width1575 mm

Height1720 mm

Clearance180 mm

Width1825 mm

Wheel size215/70 R16

Wheelbase2715 mm

Length4685 mm

Number of seater5

Disc size6.5x16 ET35, 6.5x17 ET35

Body typeCrossover

Pitch Circle DiameterDIA60.1 5x114.3 mm

Gearbox and handling

Number of gear4

Gearbox typeAutomatic

Drive wheelsFront wheel drive

Operating characteristics

Acceleration (0-100 km/h)11.0 s

Max speed180 km/h

Fuel tank capacity75 l

Fuel92

Mixed driving fuel consumption per 100 km9.4 l

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
