Toyota Isis 2004–2009

1 generation (XM10)

General information

Number of doors5

CountryJapan

Car classM

Steering wheel positionRight

At a glance

Engine1794 cm3 Gasoline

Power130 hp

GearboxAutomatic

Origin

Japan

Trim

1.8 AT (132 PS)2.0 CVT (155 PS)2.0 CVT 4WD (155 hp)

Specifications

Engine

Compression ratio10

Engine power130 hp

Engine power132 PS

Maximum torque170 N*m

Capacity1794 cm3

Engine model1zz-fe

Engine code1ZZ-FE

Number of cylinders4

Valves per cylinder4

Turnover of maximum torque4200 RPM

Max power at RPM6000 RPM

Cylinder bore79.0 mm

Stroke cycle91.5 mm

Max power (kW)97 kW

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Bodywork

Curb weight1400 kg

Rear track1465 mm

Back track width1475 mm

Front track1480 mm

Front track width1480 mm

Ground clearance160 mm

Clearance160 mm

Height1640 mm

Width1695 mm

Wheel size205/55 R16, 195/65 R15

Wheelbase2785 mm

Length4610 mm

Number of seater7

Pitch Circle DiameterDIA60.1 5x114.3 mm

Body typeMinivan

Gearbox and handling

Turning circle10.8 m

Number of gear4

Gearbox typeAutomatic

Drive wheelsFront wheel drive

Operating characteristics

Fuel tank capacity60 l

Mixed driving fuel consumption per 100 km6.9 l

Fuel92

Suspension and brakes

Rear brakesdrum

Front suspensionIndependent, spring

Back suspensionSemi-dependent, spring

Front brakesventilated disc
