Toyota Innova 2008–2011

1 generation (AN40) [restyling]

At a glance

Engine1998 cm3 Gasoline

Power136 hp

GearboxAutomatic

OriginN/A

Trim

2.0 AT 7seat (136 hp)2.0 MT 7seat (132 hp)2.0 MT 7seat (136 hp)2.0 MT 8seat (132 hp)2.0 MT 8seat (136 hp)2.5 D-4D AT 7seat (102 hp)2.5 D-4D MT 7seat (102 hp)2.5 D-4D MT 8seat (102 hp)

Specifications

Engine

Max power (kW)101 kW

Engine power136 hp

Engine power137 PS

Maximum torque181 N*m

Capacity1998 cm3

Number of cylinders4

Valves per cylinder4

Cylinder bore86 mm

Stroke cycle86 mm

Engine typeGasoline

Cylinder layoutInline

Injection typeMulti-point fuel injection

Turnover of maximum torqueto 4 000 RPM

Max power at RPMto 5 600 RPM

Bodywork

Front track1510 mm

Rear track1510 mm

Curb weight1550 kg

Height1755 mm

Ground clearance176 mm

Width1770 mm

Full weight2220 kg

Wheelbase2750 mm

Length4580 mm

Payload670 kg

Number of seater7

Body typeMinivan

Gearbox and handling

Turning circle10.8 m

Number of gear4

Gearbox typeAutomatic

Drive wheelsRear wheel drive

Operating characteristics

Mixed driving fuel consumption per 100 km10 l

City driving fuel consumption per 100 km11.5 l

Fuel tank capacity55 l

Highway driving fuel consumption per 100 km8.6 l

Fuel95

Emission standardsEURO II

Cruising rangefrom 480 to 640 km

Suspension and brakes

Rear brakesdrum

Front suspensionIndependent, Double wishbone, Stabilizer bar

Back suspensionIndependent, Multi wishbone, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.

No grades recorded for this trim yet.
