Toyota Hilux 1968–1972

1 generation (N10)

General information

Number of doors2

Car classJ

CountryJapan

Steering wheel positionLeft

At a glance

Engine1490 cm3 Gasoline

Power70 hp

GearboxManual

Origin

Japan

Trim

1.5 MT (70 hp)1.6 MT (80 PS)2.0 MT (110 PS)

Specifications

Engine

Maximum torque113 N*m

Capacity1490 cm3

Valves per cylinder2

Turnover of maximum torque2600 RPM

Engine code2R

Engine model2R

Number of cylinders4

Max power at RPM5000 RPM

Max power (kW)51 kW

Engine power69 PS

Engine power70 hp

Cylinder bore78.0 mm

Stroke cycle78.0 mm

Compression ratio8

Injection typecarburetor

Engine placementFront, longitudinal

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Timing beltOHV

Bodywork

Curb weight1025 kg

Front track width1290 mm

Back track width1290 mm

Height1570 mm

Width1580 mm

Clearance190 mm

Full weight2190 kg

Wheelbase2540 mm

Number of seater3

Length4215 mm

Body typePickup

Gearbox and handling

Number of gear4

Gearbox typeManual

Drive wheelsRear wheel drive

Operating characteristics

Max speed125 km/h

Fuel tank capacity46 l

Fuel80

Suspension and brakes

Back suspensionDependent, spring

Front brakesDisc

Rear brakesdrum

Front suspensionIndependent, spring
