Toyota Highlander 2013–2016

3 generation (XU50)
General information
Number of doors5
Car classE
CountryJapan
Steering wheel positionLeft
At a glance
Engine2672 cm3 Gasoline
Power185 hp
GearboxAutomatic
OriginJapan
Trim
2.7 AT (188 PS)3.5 AT (274 hp)3.5 AT AWD (249 PS)3.5 AT FWD (270 hp)3.5 CVT (284 hp)3.5 Hybrid CVT (231 hp)

Specifications

Engine
Compression ratio10
Stroke cycle105.0 mm
Max power (kW)138 kW
Engine power185 hp
Engine power188 PS
Engine model1ar-fe
Engine code1AR-FE
Maximum torque252 N*m
Capacity2672 cm3
Number of cylinders4
Valves per cylinder4
Turnover of maximum torque4200 RPM
Max power at RPM5800 RPM
Cylinder bore90.0 mm
Injection typedistributed injection (multipoint)
Timing beltDOHC
Engine placementFront, transverse
Engine typeGasoline
Cylinder layoutinline
Boost typenone
Bodywork
Front track1635 mm
Front track width1635 mm
Rear track1650 mm
Back track width1650 mm
Height1730 mm
Curb weight1880 kg
Width1925 mm
Ground clearance197 mm
Clearance197 mm
Max trunk capacity2370 l
Wheel size245/60 R18
Full weight2625 kg
Wheelbase2790 mm
Trailer load (with brakes)3305 kg
Min trunk capacity391 l
Length4865 mm
Payload670 kg
Number of seater7
Body typeCrossover
Pitch Circle DiameterDIA60.1 5x114.3 mm
Gearbox and handling
Turning circle11.8 m
Number of gear6
Gearbox typeAutomatic
Drive wheelsFront wheel drive
Operating characteristics
Acceleration (0-100 km/h)10.3 s
City driving fuel consumption per 100 km13.3 l
Max speed180 km/h
CO2 emissions230 g/km
Fuel tank capacity72 l
Highway driving fuel consumption per 100 km7.9 l
Fuel95
Mixed driving fuel consumption per 100 km9.9 l
Emission standardsEuro 5
Cruising rangefrom 540 to 910 km
Suspension and brakes
Rear brakesDisc
Front suspensionIndependent, spring
Back suspensionIndependent, spring
Front brakesventilated disc
