Toyota Fortuner 2011–2015
1 generation (AN50/AN60) [Restyling-2]At a glance
Engine2694 cm3 Gasoline
Power158 hp
GearboxAutomatic
OriginN/A
Trim
2.5 AT AWD (144 PS)2.5 AT RWD (144 PS)2.5G MT (144 hp)2.5 MT AWD (144 PS)2.5 MT RWD (144 PS)2.7 AT (158 hp)2.7 AT 4WD (158 hp)2.7 AT AWD (160 PS)2.7 AT RWD (160 PS)2.7 MT (158 hp)2.7 MT 4WD (158 hp)2.7 MT AWD (160 PS)2.7 MT RWD (160 PS)3.0 AT (163 hp)3.0 AT 4WD (163 hp)3.0 AT AWD (171 PS)3.0 AT RWD (163 hp)3.0 AT RWD (171 PS)3.0 MT AWD (171 PS)3.0 MT RWD (163 hp)3.0 MT RWD (171 PS)4.0 AT 4WD (235 hp)4.0 AT AWD (235 PS)4.0 AT RWD (235 PS)4.0 MT 4WD (235 hp)4.0 MT AWD (235 PS)4.0 MT RWD (235 PS)
Specifications
Engine
Max power (kW)118 kW
Engine power158 hp
Engine power160 PS
Maximum torque241 N*m
Capacity2694 cm3
Number of cylinders4
Valves per cylinder4
Cylinder bore95 mm
Stroke cycle95 mm
Engine typeGasoline
Cylinder layoutInline
Injection typeMulti-point fuel injection
Turnover of maximum torqueto 3 800 RPM
Max power at RPMto 5 200 RPM
Bodywork
Front track1540 mm
Rear track1540 mm
Curb weight1780 kg
Height1795 mm
Width1840 mm
Ground clearance220 mm
Full weight2350 kg
Wheelbase2750 mm
Length4705 mm
Number of seater5
Payload570 kg
Body typeCrossover
Gearbox and handling
Turning circle11.6 m
Number of gear4
Gearbox typeAutomatic
Drive wheelsRear wheel drive
Operating characteristics
Fuel tank capacity80 l
Fuel95
Suspension and brakes
Rear brakesdrum
Front suspensionIndependent, Double wishbone, spring, Stabilizer bar
Back suspensionMulti wishbone, Trailing arms, Stabilizer bar
Front brakesventilated disc
Grades & features
Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
No grades recorded for this trim yet.
