Toyota Crown 2012–2015

14 Generation (S210)

General information

Number of doors4

Car classE

CountryJapan

Steering wheel positionLeft/Right

At a glance

Engine2499 cm3 Gasoline

Power200 hp

GearboxAutomatic

Origin

Japan

Series

Athlete Sedan 4-doors Royal Sedan 4-doors

Trim

2.5 AT AWD (203 hp)2.5 AT RWD (203 PS)2.5 CVT (321 PS)2.5 Hybrid CVT AWD (178 hp)2.5 Hybrid CVT RWD (178 hp)3.5 AT (315 hp)

Specifications

Engine

Compression ratio12

Max power (kW)149 kW

Engine power200 hp

Engine power203 PS

Maximum torque243 N*m

Capacity2499 cm3

Valves per cylinder4

Turnover of maximum torque4800 RPM

Engine model4gr-fse

Engine code4GR-FSE

Number of cylinders6

Max power at RPM6400 RPM

Stroke cycle77.0 mm

Cylinder bore83.0 mm

Injection typedirect injection (direct)

Timing beltDOHC

Engine placementFront, longitudinal

Engine typeGasoline

Boost typenone

Cylinder layoutV-type

Bodywork

Ground clearance145 mm

Clearance145 mm

Height1460 mm

Curb weight1540 kg

Front track1545 mm

Rear track1545 mm

Front track width1545 mm

Back track width1545 mm

Width1800 mm

Full weight1815 kg

Wheel size225/50 R17

Payload275 kg

Wheelbase2850 mm

Length4895 mm

Number of seater5

Pitch Circle DiameterDIA60.1 5x114.3 mm

Body typeSedan

Gearbox and handling

Turning circle10.4 m

Number of gear6

Gearbox typeAutomatic

Drive wheelsRear wheel drive

Operating characteristics

Fuel tank capacity71 l

Mixed driving fuel consumption per 100 km8.8 l

Fuel95

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
