Toyota Carina ED 1985–1987

1 generation (T160)

General information

Number of doors4

Car classD

CountryJapan

Steering wheel positionRight

At a glance

Engine1832 cm3 Gasoline

Power111 hp

GearboxManual

Origin

Japan

Trim

1.8 (113 PS)2.0 (140 PS)

Specifications

Engine

Engine power111 hp

Engine power113 PS

Maximum torque164 N*m

Capacity1832 cm3

Engine model1s-elu

Engine code1S-ELU

Valves per cylinder2

Number of cylinders4

Turnover of maximum torque4000 RPM

Max power at RPM5400 RPM

Cylinder bore80.5 mm

Max power (kW)83 kW

Compression ratio9

Stroke cycle90 mm

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Timing beltSOHC

Bodywork

Height1365 mm

Back track width1435 mm

Front track width1470 mm

Clearance160 mm

Wheel size165/80 R13

Width1670 mm

Wheelbase2525 mm

Length4350 mm

Number of seater5

Disc size5.5x13 ET39, 5x13 ET39, 6x14 ET45

Pitch Circle DiameterDIA60.1 5x100 mm

Body typeSedan

Gearbox and handling

Number of gear5

Drive wheelsFront wheel drive

Gearbox typeManual

Operating characteristics

Acceleration (0-100 km/h)10.8 s

Max speed155 km/h

Fuel tank capacity50 l

Mixed driving fuel consumption per 100 km7.4 l

Fuel92

Suspension and brakes

Back suspensionDependent, spring

Front brakesDisc

Front suspensionIndependent, spring

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
