Toyota Carina ED 1993–1995

3 generation (T200)

General information

Number of doors4

Car classD

CountryJapan

Steering wheel positionRight

At a glance

Engine1838 cm3 Gasoline

Power123 hp

GearboxManual

Origin

Japan

Trim

1.8 (120 PS)1.8 (125 PS)2.0 (140 PS)2.0 (165 PS)2.0 (170 PS)2.0 (175 PS)2.0 (180 hp)

Specifications

Engine

Engine power123 hp

Engine power125 PS

Maximum torque162 N*m

Capacity1838 cm3

Engine model1zz-fe

Number of cylinders4

Valves per cylinder4

Turnover of maximum torque4600 RPM

Engine code4S-FE

Max power at RPM6000 RPM

Cylinder bore82.5 mm

Stroke cycle86 mm

Max power (kW)92 kW

Compression ratio9.5

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Bodywork

Curb weight1120 kg

Height1325 mm

Clearance145 mm

Back track width1490 mm

Front track width1510 mm

Full weight1700 kg

Width1740 mm

Wheel size185/70 R14

Wheelbase2535 mm

Length4500 mm

Number of seater5

Disc size6x14 ET45

Pitch Circle DiameterDIA60.1 5x100 mm

Body typeSedan

Gearbox and handling

Number of gear5

Drive wheelsFront wheel drive

Gearbox typeManual

Operating characteristics

Acceleration (0-100 km/h)15.0 s

Max speed200 km/h

Highway driving fuel consumption per 100 km4.0 l

Fuel tank capacity60 l

City driving fuel consumption per 100 km6.8 l

Fuel92

Suspension and brakes

Rear brakesdrum

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
