Toyota bB 2003–2005

1 generation (XP30) [restyling]

General information

Number of doors5

CountryJapan

Car classM

Steering wheel positionRight

At a glance

Engine1297 cm3 Gasoline

Power91 hp

GearboxAutomatic

Origin

Japan

Trim

1.3 AT 2WD (87 PS)1.3 AT (92 PS)1.5 AT (109 PS)1.5 AT 2WD (109 hp)1.5 AT 4WD (105 PS)

Specifications

Engine

Compression ratio10

Maximum torque123 N*m

Capacity1297 cm3

Number of cylinders4

Valves per cylinder4

Turnover of maximum torque4400 RPM

Max power at RPM6000 RPM

Max power (kW)68 kW

Cylinder bore72 mm

Stroke cycle79.7 mm

Engine power91 hp

Engine power92 PS

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Engine modelk3-ve

Engine codeK3-VE

Boost typenone

Bodywork

Curb weight1030 kg

Full weight1305 kg

Height1355 mm

Back track width1420 mm

Front track width1450 mm

Clearance150 mm

Width1690 mm

Wheel size185/65 R15

Wheelbase2500 mm

Length3945 mm

Number of seater5

Pitch Circle DiameterDIA54.1 4x100 mm

Body typeMinivan

Gearbox and handling

Number of gear4

Gearbox typeAutomatic

Drive wheelsFront wheel drive

Operating characteristics

Acceleration (0-100 km/h)10.0 s

Max speed155 km/h

Fuel tank capacity45 l

Highway driving fuel consumption per 100 km6.1 l

Mixed driving fuel consumption per 100 km6.2 l

City driving fuel consumption per 100 km9.0 l

Fuel95

Suspension and brakes

Rear brakesdrum

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc
