Toyota Alphard 2005–2008

1 generation (AH10) [restyling]

General information

Number of doors5

CountryJapan

Steering wheel positionLeft/Right

Car classM

At a glance

Engine2362 cm3 Gasoline

Power157 hp

GearboxAutomatic

Origin

Japan

Trim

2.4 AT (159 PS)2.4 AT 4WD (159 hp)2.4hyb CVT (130 hp) 4WD 3.0 AT (220 hp)3.0 AT 4WD (220 PS)

Specifications

Engine

Max power (kW)117 kW

Engine power157 hp

Engine power159 PS

Maximum torque220 N*m

Capacity2362 cm3

Engine code2AZ-FE

Number of cylinders4

Valves per cylinder4

Turnover of maximum torque4000 RPM

Max power at RPM5600 RPM

Cylinder bore88.5 mm

Stroke cycle96 mm

Compression ratio9.8

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Bodywork

Back track width1540 mm

Rear track1550 mm

Front track width1560 mm

Front track1570 mm

Ground clearance160 mm

Clearance160 mm

Curb weight1780 kg

Width1830 mm

Height1935 mm

Wheel size205/65 R16, 225/55 R17

Wheelbase2950 mm

Length4865 mm

Number of seater7

Pitch Circle DiameterDIA60.1 5x114.3 mm

Body typeMinivan

Gearbox and handling

Turning circle11.6 m

Number of gear4

Drive wheelsAll wheel drive (AWD)

Gearbox typeAutomatic

Operating characteristics

Mixed driving fuel consumption per 100 km10.6 l

Acceleration (0-100 km/h)11.0 s

Fuel tank capacity70 l

Fuel92

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
