Toyota Alphard 2008–2011

2 generation (AH20)

At a glance

Engine2362 cm3 Gasoline

Power165 hp

GearboxAutomatic

OriginN/A

Series

JDM minivan 5-doors Minivan

Trim

2.4 AT (165 hp)2.4 CVT (150 hp)2.4 CVT (170 hp)3.5 AT (265 hp)3.5 AT (266 hp)3.5 AT (275 PS)

Specifications

Engine

Max power (kW)123 kW

Engine power165 hp

Engine power167 PS

Maximum torque226.5 N*m

Capacity2362 cm3

Number of cylinders4

Valves per cylinder4

Cylinder bore88.5 mm

Stroke cycle96 mm

Engine typeGasoline

Cylinder layoutInline

Injection typeMulti-point fuel injection

Turnover of maximum torqueto 4 000 RPM

Max power at RPMto 6 000 RPM

Bodywork

Front track1580 mm

Rear track1585 mm

Ground clearance170 mm

Width1830 mm

Height1905 mm

Wheelbase2950 mm

Length4850 mm

Number of seater7

Body typeMinivan

Gearbox and handling

Turning circle11.4 m

Number of gear4

Drive wheelsAll wheel drive (AWD)

Gearbox typeAutomatic

Operating characteristics

Fuel tank capacity65 l

Fuel92

Emission standardsEURO IV

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, McPherson Struts, spring

Back suspensionTorsion beam, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.

No grades recorded for this trim yet.
