Toyota Alphard 2023–2026

4 generation (AH40)

General information

Number of doors5

CountryJapan

Steering wheel positionLeft/Right

Car classM

At a glance

Engine2487 cm3 Hybrid

Power188 hp

GearboxContinuously variable transmission (CVT)

Origin

Japan

Trim

2.5 CVT (190 PS)2.5 CVT 4WD (182 PS)2.5 CVT 4WD (190 PS)

Specifications

Engine

Stroke cycle103.4 mm

Max power (kW)140 kW

Engine power188 hp

Engine power190 PS

Maximum torque236 N*m

Capacity2487 cm3

Number of cylinders4

Valves per cylinder4

Turnover of maximum torque4500 RPM

Max power at RPM6000 RPM

Cylinder bore87.5 mm

Engine modelA25A-FXS

Engine codeA25A-FXS

Injection typecombined injection (direct-distributed)

Timing beltDOHC

Engine placementFront, transverse

Engine typeHybrid

Cylinder layoutinline

Boost typeTurbocharged

Bodywork

Clearance150 mm

Front track width1600 mm

Back track width1600 mm

Width1850 mm

Height1935 mm

Curb weight2160 kg

Wheel size225/60 R18

Full weight2545 kg

Wheelbase3000 mm

Length4995 mm

Number of seater7

Body typeMinivan

Gearbox and handling

Gearbox typeContinuously variable transmission (CVT)

Drive wheelsFront wheel drive

Operating characteristics

CO2 emissions125 g/km

Highway driving fuel consumption per 100 km5.2 l

Mixed driving fuel consumption per 100 km5.6 l

Fuel tank capacity60 l

City driving fuel consumption per 100 km6.4 l

Fuel95

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc
