Toyota Alphard 2017–2023

3 generation (AH30) [restyling]

General information

Number of doors5

CountryJapan

Steering wheel positionLeft/Right

Car classM

At a glance

Engine2493 cm3 Hybrid

Power152 hp

GearboxContinuously variable transmission (CVT)

Origin

Japan

Trim

2.5 CVT (182 hp)2.5 CVT AWD (152 PS)2.5 CVT AWD (182 hp)2.5 Hybrid CVT (152 hp)3.5 AT (300 PS)3.5 AT AWD (300 PS)

Specifications

Engine

Compression ratio10.8

Max power (kW)113 kW

Engine power152 hp

Engine power154 PS

Maximum torque206 N*m

Capacity2493 cm3

Engine model2AR-FXE

Engine code2AR-FXE

Number of cylinders4

Valves per cylinder4

Turnover of maximum torque4800 RPM

Cylinder bore90.0 mm

Stroke cycle98.0 mm

Injection typedirect injection (direct)

Timing beltDOHC

Engine placementFront, transverse

Engine typeHybrid

Cylinder layoutinline

Boost typenone

Max power at RPMto 5 700 RPM

Bodywork

Ground clearance160 mm

Front track1600 mm

Back track width1600 mm

Rear track1605 mm

Front track width1625 mm

Clearance165 mm

Width1850 mm

Height1945 mm

Wheel size215/65 R16

Curb weight2240 kg

Full weight2625 kg

Wheelbase3000 mm

Payload385 kg

Length4945 mm

Number of seater7, 8

Pitch Circle DiameterDIA60.1 5x114.3 mm

Body typeMinivan

Gearbox and handling

Turning circle11.2 m

Drive wheelsAll wheel drive (AWD)

Gearbox typeContinuously variable transmission (CVT)

Operating characteristics

CO2 emissions126 g/km

Highway driving fuel consumption per 100 km6.4 l

Fuel tank capacity65 l

Mixed driving fuel consumption per 100 km6.8 l

City driving fuel consumption per 100 km7.9 l

Fuel95

Emission standardsEuro 5

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc

Accumulator battery

Battery capacity1.6 KW⋅h

Battery typeNickel metal hydride (NiMH)

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
