Toyota 4Runner 2009–2014

5 generation (N280)

General information

Number of doors5

Car classJ

CountryJapan

Steering wheel positionLeft

At a glance

Engine2693 cm3 Gasoline

Power157 hp

GearboxAutomatic

Origin

Japan

Trim

2.7 AT (157 hp)4.0 AT (270 hp)4.0 AT (273 PS)4.0 AT 4WD (270 hp)

Specifications

Engine

Compression ratio10.4

Max power (kW)115 kW

Engine power156 PS

Engine power157 hp

Maximum torque241 N*m

Capacity2693 cm3

Engine model2tr-fe

Engine code2TR-FE

Turnover of maximum torque3800 RPM

Number of cylinders4

Valves per cylinder4

Max power at RPM5200 RPM

Cylinder bore94.0 mm

Stroke cycle95.0 mm

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, longitudinal

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Bodywork

Min trunk capacity1336 l

Front track1605 mm

Rear track1605 mm

Front track width1605 mm

Back track width1605 mm

Height1781 mm

Width1925 mm

Curb weight1948 kg

Ground clearance229 mm

Clearance229 mm

Max trunk capacity2540 l

Wheel size265/70 R17

Full weight2676 kg

Wheelbase2789 mm

Length4823 mm

Number of seater5, 7

Body typeCrossover

Pitch Circle DiameterDIA106 6x139.7 mm

Gearbox and handling

Number of gear4

Gearbox typeAutomatic

Drive wheelsRear wheel drive

Operating characteristics

Highway driving fuel consumption per 100 km10.2 l

Mixed driving fuel consumption per 100 km11.8 l

City driving fuel consumption per 100 km13.1 l

Fuel tank capacity87 l

Fuel92

Suspension and brakes

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc

Rear brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
