Suzuki Jimny 1970–1981

1 generation (LJ10 / LJ20 / SJ10 / SJ20)

General information

Number of doors2

Car classJ

CountryJapan

Steering wheel positionRight

At a glance

Engine359 cm3 Gasoline

Power28 hp

GearboxManual

Origin

Japan

Trim

0.4 MT 4WD (25 hp)0.4 MT 4WD (28 hp)0.5 MT 4WD (26 PS)0.5 MT 4WD (33 PS)0.8 MT 4WD (41 PS)

Specifications

Engine

Number of cylinders2

Max power (kW)21 kW

Engine power28 hp

Engine power29 PS

Capacity359 cm3

Maximum torque36 N*m

Turnover of maximum torque5000 RPM

Max power at RPM5500 RPM

Compression ratio6

Cylinder bore61.0 mm

Stroke cycle61.5 mm

Injection typecarburetor

Engine placementFront, longitudinal

Engine typeGasoline

Cylinder layoutinline

Engine codeL50

Boost typenone

Bodywork

Front track width1190 mm

Back track width1200 mm

Width1395 mm

Height1685 mm

Wheelbase1930 mm

Clearance240 mm

Length3170 mm

Number of seater4

Curb weight600 kg

Body typeCrossover

Gearbox and handling

Number of gear4

Drive wheelsAll wheel drive (AWD)

Gearbox typeManual

Operating characteristics

Acceleration (0-100 km/h)32.0 s

Fuel tank capacity40 l

Max speed80 km/h

Fuel92

Suspension and brakes

Front suspensionDependent, spring

Back suspensionDependent, spring

Front brakesdrum

Rear brakesdrum

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
