Suzuki Ertiga 2018–2022

2 generation (NC / NC22S / NC42S / NC52S)

General information

Number of doors5

CountryJapan

Steering wheel positionLeft/Right

Car classM

At a glance

Engine1462 cm3 Gasoline

Power103 hp

GearboxManual

Origin

Japan

Trim

1.5 AT (105 PS)1.5 MT (105 PS)

Specifications

Engine

Engine power103 hp

Engine power105 PS

Compression ratio10.5

Maximum torque138 N*m

Capacity1462 cm3

Number of cylinders4

Valves per cylinder4

Turnover of maximum torque4400 RPM

Max power at RPM6000 RPM

Cylinder bore74 mm

Max power (kW)77 kW

Stroke cycle85 mm

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Engine codeK15B

Boost typenone

Bodywork

Curb weight1090 kg

Front track width1510 mm

Back track width1520 mm

Height1690 mm

Full weight1695 kg

Width1735 mm

Clearance180 mm

Wheel size185/65 R15

Wheelbase2740 mm

Length4395 mm

Min trunk capacity550 l

Number of seater7

Max trunk capacity803 l

Body typeMinivan

Gearbox and handling

Number of gear5

Drive wheelsFront wheel drive

Gearbox typeManual

Operating characteristics

Max speed180 km/h

Fuel tank capacity45 l

Fuel92

Suspension and brakes

Rear brakesdrum

Front suspensionIndependent, spring

Back suspensionSemi-independent, torsion

Front brakesventilated disc
