Suzuki Ertiga 2016–2018

1 generation (ZE / ZE81S / ZG81S) [Restyling]

General information

Number of doors5

CountryJapan

Steering wheel positionLeft/Right

Car classM

At a glance

Engine1248 cm3 Diesel

Power89 hp

GearboxManual

Origin

Japan

Trim

1.3 MT (90 PS)1.4 AT (95 PS)1.4 MT (95 PS)

Specifications

Engine

Capacity1248 cm3

Turnover of maximum torque1750 RPM

Compression ratio17.6

Maximum torque200 N*m

Number of cylinders4

Valves per cylinder4

Max power at RPM4000 RPM

Max power (kW)66 kW

Cylinder bore69.6 mm

Stroke cycle82 mm

Engine power89 hp

Engine power90 PS

Injection typeCommon rail (diesel)

Engine codeD13A

Engine typeDiesel

Timing beltDOHC

Engine placementFront, transverse

Cylinder layoutinline

Boost typeTurbocharged

Bodywork

Curb weight1260 kg

Min trunk capacity135 l

Front track width1480 mm

Back track width1490 mm

Height1685 mm

Width1695 mm

Clearance185 mm

Wheel size195/55 R16, 205/45 R17, 185/65 R15

Wheelbase2740 mm

Length4265 mm

Number of seater7

Max trunk capacity736 l

Pitch Circle DiameterDIA60.1 5x114.3 mm

Body typeMinivan

Gearbox and handling

Number of gear5

Drive wheelsFront wheel drive

Gearbox typeManual

Operating characteristics

Fuel tank capacity45 l

Mixed driving fuel consumption per 100 km4.8 l

Fueldiesel

Suspension and brakes

Rear brakesdrum

Front suspensionIndependent, spring

Back suspensionSemi-dependent, spring

Front brakesventilated disc
