Nissan NV 2011–2021

1 generation (F80)

At a glance

Engine3954 cm3 Gasoline

Power261 hp

GearboxAutomatic

OriginN/A

Trim

4.0 AT (261 hp)5.6 AT (317 hp)

Specifications

Engine

Max power (kW)195 kW

Engine power261 hp

Engine power265 PS

Maximum torque381 N*m

Capacity3954 cm3

Valves per cylinder4

Number of cylinders6

Stroke cycle92 mm

Cylinder bore95.5 mm

Engine typeGasoline

Injection typeMulti-point fuel injection

Turnover of maximum torqueto 4 000 RPM

Max power at RPMto 5 600 RPM

Cylinder layoutV-type

Bodywork

Cargo compartment volume0.8 m3

Payload1104 kg

Front track1745 mm

Rear track1750 mm

Width2029 mm

Ground clearance206 mm

Height2134 mm

Curb weight3040 kg

Wheelbase3711 mm

Full weight4318 kg

Cargo compartment (Length x Width x Height)480x1636x1363 mm

Trailer load (with brakes)5225 kg

Length6111 mm

Loading height729 mm

Number of seater8

Body typeMinivan

Gearbox and handling

Turning circle11.48 m

Number of gear5

Gearbox typeAutomatic

Drive wheelsRear wheel drive

Operating characteristics

Fuel tank capacity106 l

Fuel92

Suspension and brakes

Front suspensionIndependent, Double wishbone, Stabilizer bar

Back suspensionSolid axle, Multi wishbone, Stabilizer bar

Front brakesventilated disc

Rear brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.

No grades recorded for this trim yet.
