Nissan Wingroad 2005–2018

3 generation (Y12)

General information

Number of doors5

Car classC

CountryJapan

Steering wheel positionRight

At a glance

Engine1498 cm3 Gasoline

Power107 hp

GearboxAutomatic

Origin

Japan

Trim

1.5 AT (109 PS)1.5 AT 4WD (109 hp)1.5 CVT (109 PS)1.8 CVT (109 hp)1.8 CVT (128 PS)

Specifications

Engine

Engine power107 hp

Engine power109 PS

Maximum torque148 N*m

Capacity1498 cm3

Number of cylinders4

Valves per cylinder4

Turnover of maximum torque4400 RPM

Max power at RPM6000 RPM

Cylinder bore73.6 mm

Max power (kW)80 kW

Stroke cycle88.0 mm

Compression ratio9.9

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Engine modelhr15de

Engine codeHR15DE

Cylinder layoutinline

Boost typenone

Bodywork

Curb weight1180 kg

Full weight1455 kg

Front track1480 mm

Front track width1480 mm

Rear track1485 mm

Back track width1485 mm

Ground clearance150 mm

Clearance150 mm

Height1505 mm

Width1695 mm

Wheel size175/70 R14, 185/65 R15, 195/55 R16

Wheelbase2600 mm

Min trunk capacity412 l

Length4440 mm

Number of seater5

Pitch Circle DiameterDIA60.1 4x100 mm

Body typeWagon

Gearbox and handling

Turning circle10.4 m

Number of gear4

Gearbox typeAutomatic

Drive wheelsFront wheel drive

Operating characteristics

Acceleration (0-100 km/h)10.5 s

Max speed175 km/h

Fuel tank capacity50 l

Highway driving fuel consumption per 100 km6.5 l

Mixed driving fuel consumption per 100 km7.9 l

Fuel92

City driving fuel consumption per 100 km9.8 l

Cruising rangefrom 460 to 690 km

Suspension and brakes

Rear brakesdrum

Front suspensionIndependent, spring

Back suspensionSemi-independent, torsion

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
