Nissan Titan 2003–2007

1 generation (A60)

General information

Number of doors4

Car classJ

CountryJapan

Steering wheel positionLeft

At a glance

Engine5552 cm3 Gasoline

Power300 hp

GearboxAutomatic

Origin

Japan

Series

Crew Cab pickup 4-doors King Cab pickup 4-doors Pickup One-and-a-half cabin

Trim

5.6 AT (305 PS)5.6 AT (317 hp)5.6 AT 4WD (305 hp)5.6 AT 4WD (317 hp)

Specifications

Engine

Max power (kW)224 kW

Engine power300 hp

Engine power305 PS

Valves per cylinder4

Max power at RPM4900 RPM

Maximum torque522 N*m

Capacity5552 cm3

Number of cylinders8

Stroke cycle92 mm

Cylinder bore98 mm

Compression ratio9.8

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, longitudinal

Engine typeGasoline

Boost typenone

Presence of intercoolerPresent

Turnover of maximum torqueto 3 600 RPM

Engine codeVK56DE

Engine modelVK56DE

Cylinder layoutV-type

Bodywork

Min trunk capacity1608 l

Max trunk capacity1608 l

Front track1715 mm

Rear track1715 mm

Front track width1715 mm

Back track width1715 mm

Height1930 mm

Width2002 mm

Curb weight2253 kg

Wheel size245/75 R17, 265/70 R18

Clearance264 mm

Ground clearance287 mm

Full weight2942 kg

Wheelbase3551 mm

Number of seater5

Length5695 mm

Pitch Circle DiameterDIA77.8 6x139.7 mm

Body typePickup

Gearbox and handling

Number of gear5

Drive wheelsAll wheel drive (AWD)

Gearbox typeAutomatic

Operating characteristics

Fuel tank capacity105 l

Highway driving fuel consumption per 100 km12.4 l

Mixed driving fuel consumption per 100 km14.7 l

City driving fuel consumption per 100 km16.8 l

Max speed180 km/h

Acceleration (0-100 km/h)9.0 s

Fuel92

Cruising rangefrom 630 to 850 km

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionSolid axle, Multi wishbone, Stabilizer bar

Front brakesventilated disc
