Nissan Elgrand 1997–1999

1 generation (E50)

General information

Number of doors5

CountryJapan

Car classM

Steering wheel positionRight

At a glance

Engine2953 cm3 Diesel

Power168 hp

GearboxAutomatic

Origin

Japan

Series

Minivan 5-doors Rider minivan 5-doors

Trim

3.0 TD AT (170 hp)3.0 TD AT 4WD (170 PS)3.3 AT (170 PS)3.3 AT 4WD (170 hp)3.5 AT (240 hp)3.5 AT 4WD (240 hp)

Specifications

Engine

Stroke cycle102 mm

Max power (kW)125 kW

Engine power168 hp

Engine power170 PS

Compression ratio17.9

Turnover of maximum torque1800 RPM

Capacity2953 cm3

Maximum torque353 N*m

Max power at RPM3600 RPM

Number of cylinders4

Valves per cylinder4

Cylinder bore96 mm

Engine typeDiesel

Timing beltDOHC

Engine placementFront, longitudinal

Injection typeHPFP (Diesel)

Cylinder layoutinline

Boost typeTurbocharged

Engine modelzd30ddti

Engine codeZD30DDTI

Bodywork

Height1305 mm

Ground clearance140 mm

Clearance140 mm

Front track1510 mm

Front track width1510 mm

Rear track1515 mm

Back track width1515 mm

Width1775 mm

Curb weight2060 kg

Wheel size215/65 R15

Full weight2500 kg

Wheelbase2900 mm

Length4740 mm

Number of seater8

Pitch Circle DiameterDIA100 6x139.7 mm

Body typeMinivan

Gearbox and handling

Turning circle11.2 m

Number of gear4

Gearbox typeAutomatic

Drive wheelsRear wheel drive

Operating characteristics

City driving fuel consumption per 100 km10.2 l

Fuel tank capacity76 l

Highway driving fuel consumption per 100 km7.8 l

Mixed driving fuel consumption per 100 km9.6 l

Fueldiesel

Cruising rangefrom 670 to 870 km

Suspension and brakes

Rear brakesDisc

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
