Nissan Elgrand 2002–2004

2 generation (E51)

General information

Number of doors5

CountryJapan

Steering wheel positionLeft/Right

Car classM

At a glance

Engine2495 cm3 Gasoline

Power184 hp

GearboxAutomatic

Origin

Japan

Series

ME51 minivan 5-doors ME51 Rider minivan 5-doors MNE51 minivan 5-doors NE51 minivan 5-doors NE51 Rider minivan 5-doors

Trim

2.5 AT 4WD (186 PS)3.5 AT (240 hp)3.5 AT 4WD (240 hp)

Specifications

Engine

Compression ratio10

Max power (kW)137 kW

Engine power184 hp

Engine power186 PS

Maximum torque232 N*m

Capacity2495 cm3

Turnover of maximum torque3200 RPM

Valves per cylinder4

Number of cylinders6

Max power at RPM6000 RPM

Stroke cycle73.3 mm

Cylinder bore85 mm

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, longitudinal

Engine typeGasoline

Boost typenone

Engine modelvq25de

Engine codeVQ25DE

Cylinder layoutV-type

Bodywork

Front track1535 mm

Front track width1535 mm

Rear track1540 mm

Back track width1540 mm

Clearance155 mm

Width1795 mm

Height1920 mm

Curb weight2010 kg

Full weight2045 kg

Wheel size215/60 R17, 215/65 R16

Wheelbase2950 mm

Length4795 mm

Number of seater6, 7, 8

Pitch Circle DiameterDIA66.1 5x114.3 mm

Body typeMinivan

Gearbox and handling

Number of gear5

Drive wheelsAll wheel drive (AWD)

Gearbox typeAutomatic

Operating characteristics

Highway driving fuel consumption per 100 km10.2 l

Mixed driving fuel consumption per 100 km11.9 l

City driving fuel consumption per 100 km12.8 l

Fuel tank capacity76 l

Fuel95

Cruising rangefrom 590 to 750 km

Suspension and brakes

Front brakesDisc

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Rear brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
