Nissan Cube 2002–2008

2 generation (Z11)

General information

Number of doors5

CountryJapan

Car classM

Steering wheel positionRight

At a glance

Engine1386 cm3 Gasoline

Power97 hp

GearboxAutomatic

Origin

Japan

Trim

1.4 AT 4WD (98 hp)1.4 AT (98 PS)1.4 CVT (98 PS)1.5 AT (109 PS)1.5 AT 4WD (109 hp)1.5 CVT (109 PS)

Specifications

Engine

Maximum torque137 N*m

Capacity1386 cm3

Turnover of maximum torque3200 RPM

Number of cylinders4

Valves per cylinder4

Max power at RPM5600 RPM

Max power (kW)72 kW

Cylinder bore73 mm

Stroke cycle82.8 mm

Engine power97 hp

Engine power98 PS

Compression ratio9.9

Engine modelcr14de

Engine codeCR14DE

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Bodywork

Curb weight1180 kg

Ground clearance140 mm

Clearance140 mm

Rear track1446 mm

Back track width1446 mm

Front track1461 mm

Front track width1461 mm

Width1610 mm

Height1625 mm

Wheel size175/60 R15, 175/65 R14

Wheelbase2360 mm

Length3720 mm

Number of seater4

Pitch Circle DiameterDIA60.1 4x100 mm

Body typeMinivan

Gearbox and handling

Number of gear4

Gearbox typeAutomatic

Drive wheelsFront wheel drive

Operating characteristics

Fuel tank capacity41 l

Highway driving fuel consumption per 100 km6.8 l

Mixed driving fuel consumption per 100 km8.5 l

City driving fuel consumption per 100 km9.3 l

Fuel95

Cruising rangefrom 530 to 820 km

Suspension and brakes

Rear brakesdrum

Front suspensionIndependent, spring

Back suspensionSemi-independent, torsion

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
