Nissan Cube 2000–2002

1 generation (Z10) [restyling]

General information

Number of doors5

CountryJapan

Car classM

Steering wheel positionRight

At a glance

Engine1348 cm3 Gasoline

Power85 hp

GearboxContinuously variable transmission (CVT)

Origin

Japan

Trim

1.3 AT (85 hp)1.3 CVT 4WD (85 hp)1.4 AT (101 PS)1.4 CVT (101 PS)

Specifications

Engine

Maximum torque120 N*m

Capacity1348 cm3

Number of cylinders4

Valves per cylinder4

Turnover of maximum torque4000 RPM

Max power at RPM6000 RPM

Max power (kW)63 kW

Cylinder bore72.0 mm

Stroke cycle82.8 mm

Engine power85 hp

Engine power86 PS

Compression ratio9.5

Engine codeCGA3DE

Engine modelCGA3DE

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Bodywork

Curb weight1000 kg

Back track width1335 mm

Front track width1375 mm

Clearance145 mm

Width1610 mm

Height1625 mm

Wheel size165/70 R13, 175/60 R14

Wheelbase2360 mm

Length3750 mm

Number of seater4

Disc size5.5x14 ET40, 5x13 ET40

Pitch Circle DiameterDIA60.1 4x100 mm

Body typeMinivan

Gearbox and handling

Gearbox typeContinuously variable transmission (CVT)

Drive wheelsFront wheel drive

Operating characteristics

Max speed160 km/h

Fuel tank capacity42 l

Highway driving fuel consumption per 100 km7.0 l

Mixed driving fuel consumption per 100 km8.3 l

City driving fuel consumption per 100 km8.5 l

Fuel95

Suspension and brakes

Rear brakesdrum

Front suspensionIndependent, spring

Back suspensionIndependent, spring

Front brakesventilated disc

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
