Mitsubishi eK Custom 2013–2015

1 generation (B11W)

General information

Number of doors5

Car classA

CountryJapan

Steering wheel positionRight

At a glance

Engine659 cm3 Gasoline

Power48 hp

GearboxContinuously variable transmission (CVT)

Origin

Japan

Trim

0.7 CVT (49 PS)0.7 CVT 4WD (49 PS)0.7 CVT 4WD (64 PS)0.7 CVT (64 PS)

Specifications

Engine

Compression ratio10.9

Number of cylinders3

Max power (kW)36 kW

Engine code3B20

Engine model3B20

Valves per cylinder4

Engine power48 hp

Engine power49 PS

Turnover of maximum torque5500 RPM

Maximum torque56 N*m

Max power at RPM6500 RPM

Cylinder bore65.4 mm

Stroke cycle65.4 mm

Capacity659 cm3

Injection typedistributed injection (multipoint)

Timing beltDOHC

Engine placementFront, transverse

Engine typeGasoline

Cylinder layoutinline

Boost typenone

Bodywork

Back track width1290 mm

Front track width1300 mm

Width1475 mm

Clearance150 mm

Wheel size155/65 R14

Height1620 mm

Wheelbase2430 mm

Length3395 mm

Number of seater4

Disc size4.5x14 ET46, 4.5x15 ET46

Curb weight840 kg

Pitch Circle DiameterDIA56.1 4x100 mm

Body typeHatchback

Gearbox and handling

Gearbox typeContinuously variable transmission (CVT)

Drive wheelsFront wheel drive

Operating characteristics

Max speed133 km/h

Acceleration (0-100 km/h)22.5 s

Fuel tank capacity30 l

Mixed driving fuel consumption per 100 km3.3 l

Fuel95

Suspension and brakes

Back suspensionDependent, spring

Front brakesDisc

Front suspensionIndependent, spring

Grades & features

Select a grade to see its included features. A check means standard equipment; a cross means optional or not specified.
